Indoor / Outdoor Moving Walk Escalator Public Traffic Type Escalator 8kw

Name: Indoor Outdoor Moving Walk Escalator Public Traffic Type Escalator 8kw
Brand: SUNNY
Price: 7000 USD

Quality Indoor / Outdoor Moving Walk Escalator Public Traffic Type Escalator 8kw for sale

Brand Name : SUNNY

Model Number : SN-XDW30A(small R ramp handrail)

Certification : CE,ISO9001

Place of Origin : China

MOQ : 1Set

Price : $7000~12000

Payment Terms : Western Union, T/T, L/C,Paypal

Supply Ability : 500 Set/ Year

Delivery Time : 15~30 days

Packaging Details : Wooden box

Name : Public traffic type escalator

Pedal : 1000mm

Speed : 0.5m/s

Power : 8kw

Model : Moving Walk Escalator

Used : Escalator

Warranty : 12 Months

Control system : VVVF Control System

Type : Moving Walk Escalator

Product : Moving Walk Escalator

Contact Now

Public traffic type escalator SN-XDW30A(small R ramp handrail)
Indoor / Outdoor Moving Walk Escalator Public Traffic Type Escalator 8kw

Power meter(Pedal with 1000mm speed 0.5m/s)

8KW	11KW	15KW	18.5KW	2x11KW
3.0m≤H≤4.0m	4.0m＜H≤5.2m	5.2m＜H≤7.2m	7.2m＜H≤9.0m	9.0m＜H≤10.8m
2x15kw	/	/	/	/
10.8m＜H≤12.0m	/	/	/	/

Bearing reaction

Step width	600	800	1000
R1(kN)	4.1xL2+38	4.5xL2+40	5xL2+42.5
R2(kN)	4.1xL1+26	4.5xL1+27	5xL1+28.5
R3(kN)	4.25xL+37	4.5xL+39	5.2xL+41.5

Standard specification and dimension

Model		XDW-60L	XDW-80L	XDM-100L
Step width	A	600	800	1000
Decorative width	B	1340	1540	1740
Construction Open width	C	1400	1600	1800
Handrail spacing	D	962	1162	1362
Construction Open width	E	2312	2512	2712
Support base length	F	1340	1540	1740
Rebar quantity	G	4	5	6

Specification

Instructions 1. This diagram is applicable to the civil construction of single escalators with 12m and below. 2. When the step width is 600mm or 800mm, the upper part of the truss must be extended 420mm; the support distance is ≤ 15000mm	Model		SN-XDM-1000
	Speed		0.5m/s
	Height		H≤12000mm
	Angle		30°
	Support forceR1		KN
	Support forceR2		KN
	Support forceR3		KN
	Motor Power		KW
	Power supply	Power	AC 380V/50Hz
		Illumination	AC 220V/50Hz

SN-XDW30A(small R ramp handrail) standard single-row construction layout(outdoor)

Indoor / Outdoor Moving Walk Escalator Public Traffic Type Escalator 8kw

FAQ
1. Are the elevator wire ropes durable?
The elevator wire rope has special provisions and requirements. Configuration is not only for wire rope and rated load, but also considered the size of the traction, as a result, the tensile strength of wire rope is greater than the weight of the lift. The safety factor is equipped with more than four wire rope. So it won’t break at the same time.
2. Is it dangerous for power failure suddenly during the elevator running?
If it occurs, the elevator will automatically stop due to the electrical and mechanical safety device. In case of power failure,elevator brakes will automatically taken. In addition, the power supply departments such as planned outage, prior notice are also operating.
3. Will us be hurt when it closed suddenly?
In the closing process, if people touch the hall door, the door of elevator will automatically restart without any danger. With anti clamping switch, once the gate touched, this switching action make the elevator unable to be closed and even reopened. In addition, closing force is also available here.
4. How the elevator running?
Elevators are operated with a counterweight wire rope through the (tractor) traction drive, making ups and downs on the guide rail.
5. Is the escalator installation complicated?
We believe the functions of an escalator are not necessarily proportional to the operation complexity. Therefore, escalators designed by us apply an integrated structure, so that the equipment is more precise and more efficient and allows easier and more convenient commissioning.
6. Do you have any cerifications?
Yes, we do with ISO9001 / CCC / CE Certificates for u.
